Opportunistic etiological agents causing lung infections: emerging need to transform lung-targeted delivery
Studies Investigate Extent Of Nontuberculous Mycobacterial Infections
Nontuberculous mycobacteria (NTM) can result in pulmonary and extrapulmonary infections and are primarily acquired from environmental sources, including soil and water exposed surfaces. Recent studies investigated the risk factors of NTM infections and their prevalence among patients in the United States.
Nontuberculous mycobacteria (NTM) can result in pulmonary and extrapulmonary infections and are primarily acquired from environmental sources, including soil and water exposed surfaces. Recent studies investigated the risk factors of NTM infections and their prevalence among patients in the United States.
One study used a national database of inpatient hospital encounters in order to characterize the epidemiology of skin/soft tissue (SST) and disseminated NTM infections.1 Clinical, demographic, and laboratory data was analyzed from the Cerner Healthfacts database for patients with NTM from 156 hospitals from 2000 to 2015.
A total of 63,382,356 hospital-based patients were included in the study. Of the total patients, 1193 had extrapulmonary NTM, including 651 patients with SST, and 584 patients with disseminated infections in their blood and other organs. Additionally, 53 patients also had pulmonary NTM and 42 had both SST and disseminated infections.
The results also reported the most common comorbidities as fungal infections (16%), and HIV (14%). A total of 50 deaths were reported, including 28 with disseminated infections, 19 with SST, and 3 cases with both.
Furthermore, most of the cases had Mycobacterium avium complex (MAC) (53%), followed by M. Fortuitum complex (8%), M. Abscessus (7%), M. Gordonae (7%), M. Chelonae/abscessus (6%), other rapid growers (5%), and other species (5%). Also, more cases with HIV, pulmonary NTM, or fungal infections had MAC than those without.
When considering geography, the proportion of cases with SST infections ranged from 46% in the South to 69% in the West; for disseminated cases it ranged from 35% in the West to 58% in the South. Also, it was noted that most M. Abscessus cases were in the South and most MAC cases were in the Northeast.
"This finding has important implications for clinical management of these complex patients, as more effective treatments exist for MAC relative to other NTM species," concluded the research.
Another study tested the researchers' hypothesis that the prevalence of NTM infection would be greater in recipients of drinking water treated with chloramine compared to drinking water treated with chlorine.2
The researchers performed a retrospective review and collected data from all NTM diagnostic tests performed at Michigan Medicine from January 2000 through September 2015. Data on municipal water treatment practices in Michigan cities was collected from the Environmental Protection Agency.
A total of 29,789 patients were tested for NTM over the study period and 4.1% had a positive test for NTM at least once—66% of these positive tests were from a pulmonary source. The patient diagnosis of immune deficiency or lung disease, and an older patient age, were associated with an increased risk of an NTM positive test.
While municipal water disinfectant type (chloramine) was not significantly associated with NTM infection, the use of surface water as opposed to groundwater as the primary drinking water source was associated with NTM infection.
"The positive relationship between a surface water source of municipal drinking water and NTM infection implies the potential for higher NTM abundance in surface water relative to groundwater, and suggests municipal drinking water as a potentially modifiable risk factor to reduce incidence of NTM infection," concluded the study.
References
1. Lai E, Ricotta E, Prevots D.Epidemiology of extrapulmonary nontuberculous mycobacterial infections among hospitalized patients in the United States. Presented at the American Thoracic Society 2018 International Conference. May 20, 2018; San Diego, California. Abstract A2605.
2. Caverly L, Kotlarz N, Zimbric M, Errickson J, Raskin L, LiPuma JJ. Municipal drinking water treatment practices and risk of nontuberculous mycobacterial infection. Presented at the American Thoracic Society 2018 International Conference. May 20, 2018; San Diego, California. Abstract A2604.
NewsletterStay ahead of policy, cost, and value—subscribe to AJMC for expert insights at the intersection of clinical care and health economics.
Nontuberculous Mycobacteria: Pathogens Of Growing Importance - Healio
March 15, 2017
9 min read
Add topic to email alerts
Receive an email when new articles are posted on
Please provide your email address to receive an email when new articles are posted on . Subscribe We were unable to process your request. Please try again later. If you continue to have this issue please contact customerservice@slackinc.Com.Back to Healio
Nontuberculous mycobacteria, or NTM, also called mycobacteria other than tuberculosis, traditionally have been categorized by their rate of growth and pigment production in vitro using the Runyon classification. However, with the advent of genetic techniques, species-specific identification by sequencing a number of target genes, including the 16S ribosomal RNA gene, has led to many new species of NTM being described. Currently, there are more than 125 NTM species. NTM are classified into rapidly growing mycobacteria and slow growers.
Rapid-growing mycobacteria produce nonpigmented mature colonies on agar plates in less than 7 days of incubation and include Mycobacterium fortuitum and the M. Chelonae-abscessus group.
Slow-growing NTM require more than 7 days to produce mature growth in vitro and are further divided based on pigment production into three major groups: nonchromogens, photochromogens and scotochromogens.
Nonchromogenic NTM include M. Avium and M. Intracellulare, two well-established species (together known as the MAI complex), and M. Ulcerans, M. Chimaera and M. Paratuberculosis, also known as M. Avium ssp. Paratuberculosis, are included in the MAI complex. M. Paratuberculosis is the cause of Johne's disease in ruminants such as cattle, and also perhaps Crohn's disease in humans.
Slow-growing, photochromogenic species (that is, produce pigment when grown in the light) include M. Kansasii, M. Marinum and M. Simiae. M. Simiae can cause lung infection, osteomyelitis, peritonitis, pyelonephritis and disseminated infection in immunocompromised patients.
Slow-growing, scotochromogenic species (that is, produce pigment when grown in the dark and in the light) include M. Scrofulaceum, usually causing cervical lymphadenitis in children but also rarely causing extranodal infection.
NTM are widely distributed in the environment and are commonly isolated from soil and water, including both natural and treated water sources. NTM form biofilms can survive in water systems in residential, office and health care facilities and resist chlorination. NTM can survive and grow in protozoa, their intracellular location protecting them from an otherwise hostile environment. Commercial potting soils have high NTM numbers (1 million per g) due to the inclusion of peat, and samples of patients' potting soils yielded NTM that were identical by DNA fingerprint to the NTM isolated from their lungs.
Most NTM infections are acquired from exposure to environmental sources; person-to-person transmission is rare. NTM cause skin and soft tissue, lung, lymph node, bone and joint, wound and disseminated infections.
Infections caused by M. Abscessus, M. Ulcerans and M. Chimaera are emphasized in the following sections (Table), because they in particular have been emerging problems in the past few years.
M. Abscessus Matthew E. LevisonM. Abscessus (formerly M. Chelonae ssp. Abscessus) complex is a group of rapidly growing NTM that are commonly found in soil and potable water. The M. Abscessus group includes M. Abscessus ssp. Abscessus, M. Abscessus ssp. Massiliense and M. Abscessus ssp. Bolletii. M. Abscessus ssp. Abscessus, unlike M. Bolletii, almost universally has an active inducible macrolide resistance (erm) gene, which affects treatment options. M. Abscessus can cause serious lung infections in persons often with no previously documented lung disease or with various chronic lung diseases, such as bronchiectasis or cystic fibrosis. Its presence in patients with cystic fibrosis has been a contraindication to lung transplantation. Bloodstream and disseminated infections secondary to M. Abscessus-infected indwelling venous access catheters and vascular shunts have been increasingly reported, as have pocket infections involving pacemakers and defibrillators. Outbreaks have been associated with cosmetic procedures, acupuncture and tattooing.
Donald KayeDrugs with the best in vitro activity against the M. Abscessus complex include clarithromycin, azithromycin, amikacin, imipenem and cefoxitin. The total duration of therapy usually recommended is 6 to 12 months or more. Surgical resection in patients with areas of focal severe bronchiectasis and/or cavitary pulmonary disease, aimed at decreasing the mycobacterial load and removing a reservoir of infection, when combined with multidrug antibiotic therapy, has been reported to result in more prolonged microbiologic responses.
Studies have demonstrated that dental unit waterlines (DUWLs) can become colonized with NTM, including M. Abscessus, which replicate on the interior surfaces of the DUWLs to form a biofilm. The biofilm serves as a reservoir that can seed free-floating (ie, planktonic) microorganisms in water used for dental treatment. Recently, outbreaks of M. Abscessus dental infections have been reported in Georgia in 2015 and in California in 2016. M. Abscessus-contaminated water in DUWLs used during pulpotomies (root canal procedures) in children introduced M. Abscessus into the tooth's pulp chamber and root canal during irrigation. Pulpotomy removes decay and the diseased pulp to preserve a deciduous tooth. The illness in these children had a prolonged incubation period of weeks to many months. All affected children had severe infection requiring hospitalization, and many required surgical excision of infected tissue. Some patients developed cervical or submandibular lymphadenitis, and some had multiple small pulmonary nodules on chest CT scan. The pulmonary involvement could have been due to bloodstream dissemination or either microaspiration of water or inhalation of aerosols of water from the M. Abscessus-contaminated DUWLs.
Studies have demonstrated that flushing and purging of DUWLs does not reliably improve the quality of water used during dental treatment down to less than 500 CFU/ml. The CDC's Guidelines for Infection Control in Dental Health-Care Settings — 2003 has recommended implementing infection control strategies such as self-contained water systems, chemical treatment regimens, in-line microfilters, water purifiers and different combinations of these treatments. Monitoring of dental unit water is an important component of a dental treatment water quality program.
PAGE BREAK
M. UlceransBuruli ulcer, which is caused by M. Ulcerans, is the third most common mycobacterial disease worldwide after leprosy and tuberculosis. Buruli ulcer has been reported in more than 30 countries, mainly those with tropical or subtropical wetlands, and is endemic in many foci in sub-Saharan Africa, which report the majority of cases.
However, for unknown reasons, the incidence of what is usually thought to be a tropical disease has increased dramatically in a place with a temperate climate — on the coast of Southeastern Australia — where the disease is also known as the Bairnsdale ulcer.
M. Ulcerans is likely acquired from the environment and is not believed to be transmitted from person to person, but the exact mode of transmission is unknown and may vary by geographic region. M. Ulcerans has been identified in fresh and brackish water and soil in swampy areas. Abrasions of the skin after contact with contaminated water, soil or vegetation are likely routes of entry. Vectors, in particular aquatic insects and mosquitoes, may also play a role in some locations. In Southeastern Australia, mosquitos may be a vector, and opossums, which have laboratory-confirmed M. Ulcerans skin lesions and/or M. Ulcerans PCR–positive feces, may be a reservoir.
Buruli ulcer, which initially presents as a nodule or painless indurated area on the legs or arms, progresses without pain or fever with the subsequent formation of large ulcers because of extensive destruction of skin and soft tissue that sometimes involves adjacent bone. When neglected lesions heal, scarring may cause restricted movement of limbs and permanent disabilities.
The diagnosis can be confirmed by PCR and culture. Although very slow growing (requiring 6-8 weeks of incubation), M. Ulcerans can be cultured from human lesions on media used for mycobacteria, provided the incubation temperature is kept between 29°C and 33°C (84.2-91.4°F). Genotyping of the strain can provide information about the geographical location where the patient was infected. The organism produces a unique toxin — mycolactone, which causes tissue damage and inhibits the immune response, allowing the disease to progress without pain or fever.
Treatment with rifampin, combined with either streptomycin intramuscularly, clarithromycin or moxifloxacin for 8 weeks in addition to surgical wound management to débride necrotic tissue, is used to treat Buruli ulcer.
M. ChimaeraM. Chimaera strains can be misidentified as M. Intracellulare unless sequencing techniques are used. M. Chimaera is commonly found in the environmental water and soil, and is a known cause of pulmonary disease. However, M. Chimaera infections have been recently reported to follow exposure to certain heater-cooler devices (HCDs) — specifically, the Stöckert 3T (LivaNova PLC) — during cardiac surgery. These infections include bloodstream infection, vascular graft infection, sternal wound infection, spondylodiscitis and prosthetic cardiac valve endocarditis (PVE), complicated by paravalvular leak, paravalvular abscess or cerebral abscesses.
PAGE BREAK
Initially, in June 2013, a report described two patients who developed M. Chimaera infections (PVE in one and bloodstream infection in the other) after cardiac surgery 2 years apart (2008 and 2010) at a Swiss hospital. Genotyping indicated a relatedness of the two M. Chimaera strains, but no source was found at the time. A later retrospective study uncovered a total of six patients who underwent cardiac surgery between 2008 and 2012 at this hospital and subsequently developed PVE or vascular graft infection. These infections became clinically apparent between 1.5 and 3.6 years after surgery.
M. Chimaera was found to have contaminated the water used in the 3T HCDs at the manufacturing site. Genotypes of M. Chimaera strains from patients, 3T HCDs and the manufacturing site were almost identical. The water circuits of HCDs do not come into direct contact with the patient's circulating blood; rather, studies established that M. Chimaera was aerosolized by the HCD in the operating rooms, resulting in airborne transmission to the patient's otherwise-sterile operating field during open heart surgery.
This slowly evolving outbreak has become truly global, based on the worldwide distribution of the contaminated 3T HCDs. As of November 2016, 52 cases of cardiovascular infection caused by M. Chimaera have been detected in patients who had previously undergone open heart surgery in seven countries in Europe. Cases have also been reported in the United States (at least 24 cases from at least four different hospitals), Canada, Australia and Hong-Kong.
Although HCDs, including HCDs from other manufacturers, have been found to be contaminated with waterborne pathogens, including M. Chimaera, only use of 3T HCDs has been associated with M. Chimaera cardiovascular infection. To date, no cases of postoperative infection caused by M. Chimaera associated with 3T HCDs manufactured after September 2014 have been reported. However, because of the passive reporting of cases in most countries, the long incubation period, the fact that mycobacterial cultures may not be routinely requested in patients with postoperative cardiac surgery infection, and the difficulty of identifying M. Chimaera, more cases likely go unrecognized.
Using whole-genome sequencing analysis, it has been demonstrated that M. Chimaera isolates from patients with HCD–associated infections and from the 3T HCDs from several U.S. Hospitals (in Pennsylvania and Iowa) were all highly related, which is consistent with reports from Europe.
HCDs are used in approximately 250,000 cardiopulmonary bypass surgeries annually in the U.S. The 3T HCD that has been associated with M. Chimaera infections is used in most hospitals around the world and in approximately 60% of heart bypass procedures performed in the U.S. However, the risk for infection was estimated to be low, between one in 100 and one in 1,000 in hospitals where at least one infection has been identified, but was highest in patients who had prosthetic cardiac valves or other prosthetic products implanted at the time of surgery.
Treatment has been particularly difficult. Case fatality rates approach 50%, but not all deaths were attributed to the infection. These bacteria establish biofilms on prosthetic valves or other implanted materials, which necessitate their removal. The recommended treatment regimens for a disseminated MAI complex infection include clarithromycin or azithromycin, combined with rifampin or rifabutin, and ethambutol supplemented with either an aminoglycoside, such as amikacin, or moxifloxacin. The duration of therapy is prolonged — 1 to 2 years. The optimal antimicrobial regimen for M. Chimaera infections is unknown and requires further study.
ConclusionsInfections due to NTM are increasingly recognized worldwide. NTM are ubiquitous in the environment, and exposure to NTM may be common in homes, hospitals, long-term care facilities, hemodialysis centers and dental offices, where they are located in biofilms lining the inner surface of water lines. NTM exposure may be increasing because of the popularity of hot tub/spas, misting sprays in grocery stores and in outdoor restaurants, decorative fountains, car washes, cooling towers, ultrasonic dental scaling and other high-speed dental turbine instruments, and aerosol-generating humidifiers, to mention just a few examples. NTM infections are often difficult to eradicate. A prolonged course of therapy with a combination of drugs is required. Unfortunately, persistent or recurrent infection is not uncommon.
Disclosures: Kaye and Levison report no relevant financial disclosures.
Add topic to email alerts
Receive an email when new articles are posted on
Please provide your email address to receive an email when new articles are posted on . Subscribe We were unable to process your request. Please try again later. If you continue to have this issue please contact customerservice@slackinc.Com.Back to Healio
High Rates Of Infection And Colonization By Nontuberculous Mycobacteria ...
Ozkaynak MF, Lenarsky C, Kohn D et al. Mycobacterium avium-intracellulare infections after allogeneic bone marrow transplantation in children. Am J Pediatr Hematol Oncol 1990; 12: 220.
Navari RM, Sullivan KM, Springmeyer SC et al. Mycobacterial infections in marrow transplant patients. Transplantation 1983; 36: 509–513.
White MH, Papadopoulos EB, Small TN et al. Mycobacterium haemophilum infections in bone marrow transplant recipients. Transplantation 1995; 60: 957–960.
Bekassy AN, Miorner H, Hagerstrand I, Anders F . Graft failure disclosing disseminated Mycobacterium avium-intracellulare infection. Bone Marrow Transplant 1992; 10: 476.
Martino R, Martinez C, Brunet S et al. Tuberculosis in bone marrow transplant recipients: report of two cases and review of the literature. Bone Marrow Transplant 1996; 18: 809–812.
Shah MK, Sebti A, Kiehn TE et al. Mycobacterium haemophilum in immunocompromised patients. Clin Infect Dis 2001; 33: 330–337.
Wallace RJ, Brown BA, Ohyi GO . Skin, soft tissue, and bone infections due to Mycobacterium chelonae chelonae: importance of prior corticocorticosteoid therapy, frequency of disseminated infections, and resistance to oral antimicrobials other than clarithromycin. J Infect Dis 1992; 166: 405–412.
Kurzrock R, Zander A, Vellekoop L et al. Mycobacerial pulmonary infections after allogeneic bone marrow transplantation. Am J Med 1984; 77: 35–40.
Gaviria JM, Garcia PJ, Garrido SM et al. Nontuberculous mycobacterial infections in hematopoietic stem cell transplant recipients: characteristics of respiratory and catheter-related infections. Biol Blood Marrow Transplant 2000; 6: 361.
Ward MS, Lam KV, Cannell PK, Herrmann RP . Mycobacterial central venous catheter tunnel infection: a difficult problem. Bone Marrow Transplant 1999; 24: 325–329.
Jacobson KL, Teira R, Libshitz HI et al. Mycobacterium kansasii infections in patients with cancer. Clin Infect Dis 2000; 31: 628–631.
Roy V, Weisdorf D . Mycobacterial infections following bone marrow transplantation: a 20 year retrospective review. Bone Marrow Transplant 1997; 19: 467–470.
IP MSM, Yuen KY, Woo PCY et al. Risk factors for pulmonary tuberculosis in bone marrow transplant recipients. Am J Respir Crit Care Med 1998; 158: 1173–1177.
George B, Matthews V, Srivastava V et al. Tuberculosis among allogeneic bone marrow transplant recipients in India. Bone Marrow Transplant 2001; 27: 973–975.
Budak-Alpdogan T, Tangun Y, Kalayoglu-Besisik S et al. The frequency of tuberculosis in adult allogeneic stem cell transplant recipients in Turkey. Biol Blood Marrow Transplant 2000; 6: 370–374.
Aljurf M, Gyger M, Alrajhi A et al. Mycobacterium tuberculosis infection in allogeneic bone marrow transplantation patients. Bone Marrow Transplant 1999; 24: 551–554.
Yuen KY, Woo PC, Liang RH et al. Clinical significance of alimentary tract microbes in bone marrow transplant recipients. Diagn Microbiol Infect Dis 1998; 30: 75–81.
Holland DJ, Chen SC, Chen WW, Gilbert GL . Mycobacterium neoaurum infection of a Hickman catheter in an immunosuppressed patient. Clin Infect Dis 1994; 18: 1002–1003.
Mohite U, Das M, Saikia T et al. Mycobacterial pulmonary infection post allogeneic bone marrow transplantation. Leukemia Lymphoma 2001; 40: 675–678.
Hermida G, Richard C, Baro J et al. Allogeneic BMT in a patient with CML and prior disseminated infection by Mycobacterium avium complex. Bone Marrow Transplant 1995; 16: 183–185.
Wallace RJ, Glassroth J, Griffith DE et al. Diagnosis and treatment of disease caused by nontuberculous mycobacteria. Am J Respir Crit Care Med 1997; 156: S1–S25.
Collins NH, Bleau SA, Kernan NA, O'Reilly RJ . T-cell depletion of bone marrow by treatment with soybean agglutinin and sheep red blood cell rosetting. In: Areman HJ, Deeg HJ, Sacher RA (eds) Bone Marrow and Stem Cell Processing: A Manual of Current Techniques. FA Davis: Philadelphia, PA, 1992, 171pp.
Kawanishi Y, Passweg J, Drobyski WR et al. Effect of T-cell subset dose on outcome of T-cell-depleted bone marrow transplantation. Bone Marrow Transplant 1997; 19: 1069–1077.
Horsburgh CR, Gettings J, Alexander LN, Lennox JL . Disseminated Mycobacterium avium complex disease among patients infected with Human Immunodeficiency Virus, 1985–2000. Clin Infect Dis 2001; 33: 1938–1943.
Hoyle C, Goldman JM . Life threatening infections occurring more than 3 months after BMT. Bone Marrow Transplant 1993; 14: 247–252.
Centers for Disease Control. Mycobacterium haemophilum infections—New York City metropolitan area, 1990–1991. MMWR 1991; 40: 636.
Rouleau M, Senik A, Leroy E, Vernant JP . Long-term persistence of transferred PPD-reactive T-cells after allogeneic bone marrow transplantation. Transplantation 1993; 55: 72–76.
Yuen KY, Woo PCY, Ip MSM et al. Stage-specific manifestation of mold infections in bone marrow transplant recipients: risk factors and clinical significance of positive concentrated smears. Clin Infect Dis 1997; 25: 37–42.
Jacobson MA, Hopewell PC, Yajko DM . Natural history of disseminated Mycobacterium avium complex infection in AIDS. J Infect Dis 1991; 164: 994–998.
